stainless Steel clad aluminum strip for making cooking ware

 News     |      2019-09-30 15:31
Stainless Steel clad aluminum strip for making cooking ware is made of low carbon steel (DC01-DC07), stainless steel as the base material, aluminum as the auxiliary material, according to customer needs can be single/double-sided composite. The product has the advantages of high strength, good plasticity, good corrosion resistance, good oxidation resistance, high magnetic conductivity, high thermal conductivity, good thermal reflection and recycling utilization, and is the best substitute for stainless steel. Stainless Steel clad aluminum strip for making cooking ware can be used for various surface processing and suitable for painting, coating and glazing. It can be further processed by cold bending, drawing and stamping.


Application:
IH electric rice cooker gallbladder, voltage cooker, cooker, mobile phone plate, battery box bottom plate, oil cooler and other industrial applications.

Product Name Dimension
Total thickness(mm) Aluminum thickness (%) Width(mm) Length (mm)
DC05、IF/1050、1060 0.2~10.0 5~10 ≤1000 Volume or according to user's requirements round pan material 300, 350, 360, 385, 415 and other supplies
304/1050

T2+IF+1050+430(304)+T2 0.2-5.0 metal thickness ratio can be based on customer requirements.
Note: IF is ultra-low carbon deep drawing steel.

Product Physical property Mechanical property
Density
(g/cm3)
Electrical conductivity
(m/Ω·mm2)
Peel strength(N/mm) Flexural properties Tensile strength(MPa) Elongation
(%)
DC03-07/1050、1060 7.4 11.2 ≥12 No delamination after fracture in repeated bending test ≥170 ≥20
430、304/3003 7.2 12.4 ≥12 ≥170 ≥20
