nickel copper aluminum three layer bimetal coil strip
News | 2019-11-11 18:03
Nickel copper aluminum three layer bimetal coil strip is made by using composite technology to realize solid metallurgical combination on different metal interfaces. It not only keeps the original characteristics of the material, but also keeps its superior comprehensive performance than a single material, especially the electrical conductivity of the material is significantly improved, especially the replacement material of
nickel aluminum two layer bimetal coil strip . It not only reduces the cost but also saves the resources, which is in line with the development trend of material field.
|
Alloy |
N6 |
T2 |
1060 |
|
Purity |
Ni ≥ 99.5% |
Cu+Ag ≥ 99.9% |
Al ≥99.5% |
|
nickel copper aluminum percentage |
1：1：1 ±10% |
|
Specs(mm) |
Thickness: 0.08-0.4 Tolerance:±0.01 |
Width: 2-95 Tolerance:±0.10 |
|
Hardness |
M |
Y2 |
Y |
|
Product type |
Coil, strip, sheet, or |
|
180°Bending |
M temper≥ 7 times |
Y2 temper ≥5 times |
Y temper≥2times |
|
Copper nickel aluminum binding force |
≥ 4Kgf |
|
Density |
8.92T/M3 |
|
Physical property |
Tension strength≥200MPA（M） |
Elongation 30%（M） |
|
|
Application |
It is used for bottom connection of aluminum shell battery, anode conversion of polymer battery, special welding of solar cell, etc |
