multi layered bimetal circle for cookware

 News     |      2019-10-14 17:33
In addition to the conventional stainless steel-aluminium-stainless steel-stainless steel-aluminium-stainless iron three-layer composite material, Chalco Aluminum has also developed new materials such as Copper-Stainless steel-aluminium-stainless iron, aluminium-iron two-layer plate multi layered bimetal circle, which are mainly used for high-end products such as IH electromagnetic cooker, our customers such as Philips, Super, Hertzda. And other well-known small household appliances enterprises in the field of cooking utensils and kitchen utensils.



1. Stainless  + aluminium + copper + aluminium four-layer composite material, use: high-grade IH rice cooker liner material.
Thickness: 2.8-4.5mm
Diameter Size: 375-415 mm

2. SUS304+Al+3003+Al+SUS430 five-layer steel
Thickness: 1.5-4.5 mm
Diameter: 225-580mm
Usage: High-grade cookware, kitchenware, barbecue, electrical appliances.

3. Four-layer multi layered bimetal circle is a new material developed by our company.
Combination: Copper +Stainless +Aluminum+ Stainless Steel
Characteristic: Complete magnetic conduction after bottom turning, shielding magnetic field outside, preventing magnetic field radiation, aesthetic feeling of copper shape.
Thickness: 2.3-4.5mm
Diameter: 225-580mm

Product name Series Total thickness Diameter Materials
Two layers bimetal circles Ti series 1.2mm∽18mm Ø195∽Ø580 Ti/Al ， Ti/3003 ， Ti/Cu
Two layers bimetal circle SS series 1.2mm∽18mm Ø195∽Ø580 316/Al ， 316/3003 ， 316/3004 ， 304/Al ， 304/3003 ， 304/Cu ，439/Al
Two layers bimetal circle SS series 1.2mm∽18mm Ø195∽Ø580 439/3003 ， 430/Al ， 430/3003 ， 430/Cu ， 409L/Al ，409L/Cu
Two layers bimetal circle Fe series 1.2mm∽18mm Ø195∽Ø580 SPCC/Al ， SPCC/3003 ， DC04/AL ， DC06/AL ， DC03/3003 ，DC06/3003
Three layers bimetal circle Ti series 1.5mm∽18mm Ø195∽Ø580 Ti/Al/430， Ti/3003/439
Three layers bimetal circle SS series 1.5mm∽18mm Ø195∽Ø580 316/Al/439 ，304/Al/430
Three layers bimetal circle SS series 1.5mm∽18mm Ø195∽Ø580 AL/439/AL ， AL/439/3003 ， 430/Al/430 ， AL/430/Cu ，AL/409/Cu
Three layers bimetal circle Fe series 1.5mm∽18mm Ø195∽Ø580 SPCC/Al/SPCC
Four layers bimetal circle Ti series 2.0mm∽18mm Ø195∽Ø580 Ti/Al/430/Cu ，Ti/3003/439/Cu
Four layers bimetal circle SS series 2.0mm∽18mm Ø195∽Ø580 316/Al/439/Cu ， 304/Al/430/Cu ，304/Al/409L/Cu
Five layers bimetal circle Ti series 2.0mm∽18mm Ø195∽Ø580 Ti/Al/3003/Al/439 ， Ti/Al/3004/AL/439
Five layers bimetal circle SS series 2.0mm∽18mm Ø195∽Ø580 316/Al/3003/Al/439 ， 304/Al/3003/Al/430
Special size could be customized.
