Clad plates
Typical specification of Henan
Chalco’s clad product：
Copper clad aluminum plate sheet, Stainless steel clad steel plate, Titanium clad steel plate, Copper clad steel plate, Nickel steel-clad plate, Titanium-clad copper bar, Aluminum clad steel plate, other clad plate ( Customized production according to user requirements)
Clad plate：Single side clad, or both sides clad（The shape of clad plate can provide rectangular, square and round products according to the requirements of users）Typical dimension of clad plate：
1. Thickness of cladding plate: 2～15mm，Thickness of base plate: 6～190mm
2. Width of clad plate: 100～3800mm (Beyond the maximum width can be determined by negotiation)
3. Length of clad plate: 1000～11500mm (Beyond the maximum length can be determined by negotiation)
4. OD of clad pipe: Φ500～Φ3500 (Beyond the maximum OD can be determined by negotiation)
Typical dimension of clad sheet:
1. Thickness of clad sheet: 3.30～10.50mm, Thickness of base sheet：3～10mm, Thickness of cladding sheet：0.30～0.5mm
2. Width of clad sheet：900～2000mm
3. length of clad sheet：1000-8000mm
Typical dimension of clad round bar(Titanium-clad copper bar etc):
Clad bar OD：Φ40～Φ100m, Cladding thickness：2.0～3.0mm
| Clad plate sheet | Cladding materials | Base Materials | Dimension (mm) | Standard | Main usage |
| Titanium clad steel plate | TA1, TA2, TA9,TA10 | 20R,20g,16MnR,16Mn,Q235 | 1-20/2-200*3000*6000 | GB8547-2006,ASTM B898JIS G3603 | Petrochemical, vacuum salt making, chlor-alkali, electricity, hydrometallurgy, electroplating industries |
| Titanium clad stainless steel plate | TA1, TA2, TA9,TA10 | All kinds of stainless steel | 1-20/2-200*3000*6000 | GB8546-2007 | Petrochemical, chlor-alkali, aerospace, aerospace, low temperature, food, light industry medicine |
| Titanium clad copper plate | TA1, TA2, TA9,TA10 | T,H,Q,B | 1-20/2-100*2000*4000 | Q/XB1506-94 |
Electric power industry, electrolysis industry, cooking utensils,
hydrometallurgy, etc. |
| Titanium clad aluminum plate | TA1, TA2, TA9,TA10 | L,LY,LF | 1-20/2-50*1500*4000 | Agreement | Aviation industry, cooker industry, chemical industry, naval vessels, special solder and so on. |
| Titanium clad nickel plate | TA1, TA2, TA9,TA10 | N2,N4,N6 | 1-20/2-50*2000*4000 | Agreement | Metallurgical industry, etc. |
| Ferritic stainless steel clad steel plate | 410, 0Cr13,0Cr13Al | Q235, 20R,20g16Mn,16MnR; | 1-20/2-200*4000*8000 |
GB8165-97 JB4733-1996 JIS G3601-92 ASTM A264 ， ASTM A265 |
Petrochemical, Chemical, Vacuum Salt Making, Fertilizer, Sugar Making, Paper Making, Hydrometallurgy, Hydraulic Industry, Power Station, etc. |
| austenitic stainless steel clad steel plate | 304, 304L, 316,316L, 321, 1Cr18Ni9Ti,0Cr18Ni9Ti,Cr18Ni9 | ||||
|
Heat resistant high strength stainless steel clad steel plate |
0Cr25Ni20,185,304N2205, 135,1Cr18Ni9Si1\3 |
||||
| Copper clad steel plate | T, B, H, Q | Q235, 20R,20g, 16Mn,16MnR; | 0.5-50/0.5-200*1500*6000 | GB13328-91JIS G3604-92ASTM B342 | Chemical industry, automobile industry, etc. |
| Copper clad stainless steel plate | T1, T2 | Steel and forgings | 0.5-50/0.5-200*1500*6000 |
GB13328-91 JIS G3604-92 |
Cooker industry, power industry, building materials and other industries. |
| Aluminum clad copper plate | 1060,1070,1100 | T1,T2 | 0.5-100/0.5-100*1500*4000 | Q/XB1906-94 | Electric power industry, electronics industry, etc. |
| Aluminum clad steel plate | 1060,1070,1100 | Q235, 20R,20g, 16Mn,16MnR; | 0.5-30/0.5-200*1500*4000 | Q/XB1906-94 | Electrolytic aluminum, fertilizer, transition joints, ships, aerospace, instrumentation, cryogenic engineering, etc. |
| Aluminum clad stainless steel plate | 1060,1070,1100 | Steel and forgings | 0.5-30/0.5-200*1500*4000 | Q/XB1906-94 | Automobile industry, vacuum salt making, sea salt industry, electric power industry, papermaking positive apparatus products, radio, paint, naval vessels, light industry, wear-resistant bearing bushes, etc. |
| Nickel clad steel plate | N2, N4, N6 | Q235, 20R,20g, 16Mn,16MnR; | 1-20/2-200*3000*6000 | JB4748-2002YB/T108-1997ASTM A265JIS G3602-92 | Chlor alkali, petrochemical industry, paper industry, etc. |
| Nickelclad stainless steel plate | N2, N4, N6 | Stainless steel and forgings | 1-20/2-200*3000*6000 | JB4748-2002 JIS G3602-92 | Chlor alkali, petrochemical industry, paper industry, etc. |
| Silver clad steel plate | Silver and its alloys | carbon steel | 0.5-5/1~50*1000*2000 | GB2073-80 | Electrical industry, household appliances, electronics, instrumentation, etc. |
| Silverclad copper plate | Silver and its alloys | T, B, H, Q | GB2073-80 | ||
| Gold clad silver plate | Gold and its alloys | Silver and its alloys | GB2073-80 | ||
| Zirconium clad steel plate | Zirconium and its alloy | Q235, 20R,20g, 16Mn,16MnR; | 1-5/8-200*1500*4000 | Agreement | Chemical engineering, acetic acid engineering, etc. |
| Zirconium clad stainless steel plate | Zirconium and its alloy | All kinds of stainless steel and forgings | 1-5/8-200*1500*4000 | Agreement | Chemical engineering, acetic acid engineering, etc. |
| Tantalum clad steel plate | Tantalum and its alloy | Q235, 20R,20g, 16Mn,16MnR; | 1-5/10-200*1500*2000 | Agreement | Chemical engineering, acetic acid engineering, etc. |
| Tantalum clad stainless steel plate | Tantalum and its alloy | All kinds of stainless steel and forgings | 1-5/10-200*1500*2000 | Agreement |
Chemical engineering, acetic acid engineering, etc. |
| Three-layer composite plate | Main material of inner layer | Main material of outer layer | Product specification range (mm) | Standard | Main usage |
| Titanium-steel-titanium composite plate | Q235, 20R,20g, 16Mn,16MnR; | TA1, TA2, TA9,TA10 | 1-10/1-200/1-10*~ | GB8547-2007 | Petrochemical, chemical, pharmaceutical and other industries |
| Copper-Titanium-Copper composite plate | TA1, TA2, TA9,TA10 | T1, T2 | 0.5-10/1-10/0.5-10*~ | Agreement | |
| Titanium-Copper-Steel composite plate | Q235, 20R,20g, 16Mn,16MnR; | TA1, TA2, TA9,TA10/All kinds of stainless steel and forgings | 1-10/10-200/1-10*2500*4000 | GB8547-2007 | |
| Stainless steel-steel-Stainless steel composite plate | Q235, 20R,20g, 16Mn,16MnR; | All kinds of stainless steel and forgings | 1-20/10-200/1-20*4000*8000 | Agreement | |
| Aluminum-Titanium-steel composite plate | TA1, TA2, TA9,TA10 | L,LY,LF/Q235, 20R, 20g, 16Mn,16MnR; | 1-20/1-5/8-200*1500*4000 | GB8547-2007 | |
| Copper-aluminum-Copper composite plate | L,LY,LF | T, B, H, Q | 0.5-20*~ | Agreement | |
| Aluminum-Titanium-Copper composite plate | TA1, TA2, TA9,TA10 | L, Y, FT, B,H, Q | 1-10/1-5/1-100/*~ |
